PUMA 700LY II
| Category | Item | Specification |
| Capacity | Swing over bed[mm] | 1140 |
| Swing over saddle[mm] | 1000 | |
| Workpiece | Workpiece diameter[mm] | 750 |
| Workpiece length[mm] | 3250 | |
| Chuck | Chuck size(S1)[in] | 15 |
| Optional chucks(S1)[in] | 18 21 24 32 | |
| Turning spindle 1(S1) | Barworking dia.[mm] | 164 |
| Tool post 1(T1) | No. of tool stations[ea] | 12 |
| Travels | Stroke X[mm] | 400 |
| Stroke Y[mm] | 200 | |
| Stroke Z[mm] | 3300 | |
| Stroke C[deg] | 360 | |
| Rapid traverse(X)[m/min] | 12 | |
| Rapid traverse(Y)[m/min] | 6 | |
| Rapid traverse(Z)[m/min] | 10 | |
| Rapid traverse(C)[r/min] | 14 | |
| Table | Workpiece allowable Load[kg] | 2000 |
| Table Size[mm] | D380 D450 D530 D610 D800 | |
| Category | CNC brand | Fanuc |
| CNC system | DOOSAN FANUC i Series | |
| Origin | Korea |
| Name | T1-1 | Tool holder | BMT85P | Tool shank | 32X32 | Boring bar | 80 | Position | 12 | Index time | 1.1 | Speed | 3000 | Power | 7.5(S1)!11(S6 40%) | Torque | 140 |
| Axis | X | Y | Z |
| Drive | Ball screw | Ball screw | Ball screw |
| Qty | 1 | 1 | 1 |
